PART # 8M6004829

NMEA 2000 T CONNECTOR

Part # 8M0114012

Kit includes:

• NMEA2000 power harness
• 1 male termination resistor
• 1 female termination resistor
• "T" connector

Whenever a NMEA2000 backbone is required, these are the basic components required to start that architecture.

Part # SIMYKEY

Part # ACC-RNGFR-PL-32PACK

Part # 5GH-13440-61-00BK

Superseded from Part # 5GH-13440-60-00, 5GH-13440-50-00, 5GH-13440-20-00

Part # CANDOPROYAM

DOES NOT QUALIFY FOR ADDITIONAL DISCOUNT SALES.

Part # 60V-24251-01-00

Superseded from Part # 60V-24251-00-00, 68F-24251-00-00 Filter is located between VST and the HPDI (High pressure belt driven fuel pump) on all HPDI Yamaha engines. Also order one MEDIUM PRESSURE FUEL HOSE CLAMP when replacing this filter. A tool like this one is needed to crimp the clamp FUEL CLAMP CRIMP TOOL

Part # MAR-GTWAY-KT-20

1 each 1 Ft Pigtail Buss Wire: 6Y8-82521-01-00
1 each Command Link Plus and Gateway: 6YG-8A2D0-00-00
1 each N2K Harness

This Product REPLACES Part # 6Y9-8A2D0-40-00, MAR-GTWAY-ML-09 AND MAR-GTWAY-KT-00, MAR-GTWAY-KT-10

Yamaha NMEA 2000 Gateway device. Works with both Command Link Plus color display, 6YC Display and Command Link square or round gauge systems. Kit Includes the 1 FT Pigtail buss wire required to connect the gateway to a 3-port Command link hub. A open port on the Command link 3-port hub will be needed. If one is not available, another 3 port hub will need to be installed: 6Y8-81920-01-00KIT
